PA amplifier

60W 2-zone amplifier

Item Code PAA 60M2Z
  • Disponibile

PA amplifier suitable for 70/100V or low impedance operation. 100V signals can also be managed thanks to its 2 zones. It is possible to connect up to 3 microphones and 4 line signals, each with independent volume control. Phantom power and priority function can be activated on microphone 1. It is equipped with terminals for a monitor speaker and sockets for 24V power supply. The multimedia module can play MP3 songs from microSD, USB, bluetooth. It is also endowed with FM radio. The maximum power is 60W.

Matrix
No
DC Power
24V
Bluetooth
yes
RMS power
30W
Multizone
2 zones
8 Ohm max power
60W
Impedance
4 - 8 - 16 Ohms
Voice priority function
Yes, on MIC 1 only
VU METERS
Yes
Multi zone
2 zones
Tel paging function
Yes
Mp3 player
Yes
MP3 compatible
Yes
Input connectors
XLR + RCA + Jack 6,3mm
Output connectors
terminals + RCA
Line inputs
4
Mic inputs
3
Constant voltage
70 - 100V compatible
S/N ratio
Line >85dB, Mic > 72dB
Frequency response
60 Hz - 15 Khz (+/-3dB)
Color
black
Weight
3,7 kg
Product dimensions
320 x 210 x 90mm
Power supply
AC 100 -240V DC 24V
Notes
FM radio
